Description
The ZPW767R Weatherproof Wall Mount Sounder/VAD is a ZP7 series, Ziton protocol addressable RED sounder with a built in visual alarm device (VAD), the latter approved for wall mount applications. The VAD features a clear lens with red LED element. The ZPW767R Weatherproof Wall Mount Sounder/VAD incorporates a switch setting allowing it to be assigned a unique address on a Ziton fire panel loop.
With its durable design, high sound output and VAD designed for installation up to a height of 2.4 m, the ZPW767 ensures reliability and is suitable for a variety of applications.
Sounder And VAD Combinations
Installed directly onto and powered by the ZP wiring loop, the ZPW767 enables the system designer to offer a complete addressable system on a single pair of wires. Installation costs are greatly reduced, whilst system integrity, sounder options and programmed alarm organization are significantly increased. Installation time costs are further reduced as the device connects directly into a first fix base. The ZPW767 provides synchronized audible and visual warnings from a single, loop wired unit.
Current Consumption And System Loads
High efficiency acoustic design and a low current VAD enables multiple ZPW767 devices to be connected to a fire panel loop. Depending on system requirements the ZPW767 may be set to use less power, both in sound as well as VAD output. The flash frequency may be set to 0.5 Hz (1 flash every 2 seconds) instead of 1 Hz (1 flash every second) in instances where consumption needs to be reduced. In systems where loop lengths or current requirements are excessive, the ZPW767 may be powered from an external, EN54:4 approved power supply that will automatically be supervised by the ZPW767.
- Unique optics for light management with a lens design that optimizes light dispersal, minimizing power wastage
- Up to 7.5 m coverage diameter, reducing the number of devices required to cover an area
- Coverage switch feature – for smaller areas switch down from 7.5 m to 2.5 m, reducing power consumption and saving up to 50%
- Flash rate switch feature, reducing the power consumption by up to 50%
- Soft start up for reduced current peak at start up, reducing circuit loading
- Locking base to prevent easy removal of device
- 8 Selectable tones with 4 selectable output levels
- IP66 rated for ingress protection in harsh environments
- EN54-3 and EN54-23 approved and CPR certified
