Repeater Grey IRIS/SIMPO

IMPORTANT NOTE!
Operation with Repeater Panel is supported for the following revisions of the panels:

IRIS fire alarm panel:

LCD PCB Hardware revision: 2.4 and higher
MAIN Board Firmware revision: 4.2 and higher

SIMPO fire alarm panel:

MAIN Board Firmware revision: 2.8 and higher

SKU: Repeater Grey IRIS/SIMPO Categories: Addressable Fire Alarm, Teletek Tags: repeater, Teletek

Description

The Grey Repeater IRIS/SIMPO fire alarm panel is designed to work with Teletek Electronics addressable fire alarm panels IRIS, IRIS PRO and SIMPO.

It is used to display the current events of the connected to network addressable panels.

The connection between the Grey Repeater IRIS/SIMPO panel and other addressable panels IRIS, IRIS PRO and/or SIMPO is via redundant network module based on RS485 interface.

The information for events are visualized on LCD display and LED indication for the system status.

– Maximum number of fire alarm panels in network – 64.

– Maximum distance between two panels – up to 1000m.

– Built-in real time clock.

– Latest software and firmware update – via micro USB.

Ordering

Repeater Grey IRIS/SIMPO

Teletek Repeater Grey IRIS/SIMPO Repeater IRIS/SIMPO with Grey plastic housing

Repeater Grey IRIS/SIMPO datasheet

DOWNLOAD
